Basic Info.
Model NO.
LP128-960K-F(26650)
Rechargeable
Chargeable
Discharge Rate
High Discharge Rate
Size
Large
Accessories Type
Battery
Rated Capacity
96ah
Standard Voltage
12.8V
Usage
Remote Control Boat, Remote Control Plane, Remote Control Car, Electrombile
Electrolyte
Li-ion
BMS Models
PCM-L10s200-C49
Maximal Charging Curren
150A
Maximal Continuous Discharging Current
150A
Discharge Overcurrent Protection
400±50A
Balance
Yes
Over Charge Detection Voltage
15.2±0.025V
Over Discharge Release Voltage
9.2±0.05V
Weight
14.6kg
Composed Type
4s32p
Cycle Life
2000~3000 Times
Transport Package
Fiberboard Wrapping and PVC Shrinkage Film
Specification
345(T) x 175(W) x 215(H)mm
Trademark
QUAWIN/OEM
Origin
China Guangdong Shenzhen
HS Code
850760000
Production Capacity
50000/Month
Product Description
Quick Detail:
Brand Name:QUAWIN/OEM
Model Number:LP128-960K-F(26650)
Type:Lifepo4 LFP battery
Place of Origin:Guangdong China (Mainland)
Nominal Capacity:96Ah/96000mAh
Cell Capacity:3.2V/3.0Ah
Nominal Voltage:12.8V
Charging voltage:DC:14.6V CC/CV
Optional function: intelligent battery display module
Maximal charging curren:150a
Maximal continuous Discharging current:150a
Discharge overcurrent protection:400±50A
Over charge detection voltage:15.2±0.025V
Over charge release voltage:14.2±0.025V
Over discharge detection voltage:8.0±0.05V
Over discharge release voltage:9.2±0.05V
Blanse current for single cell:56mA±5mA
BMS Models:PCM-L10S200-C49(BMS specifications can be obtained separately)
Certificate:CE,ROHS,UL,UN38.3 REACH
Pack:Fiberboard wrapping and PVC shrinkage film
Battery Pack Dimension :345(T) x 175(W) x 215(H)mm
Weight:14.3Kg
Composed Type:4S32P
Cycle life:2000~3000 times
Warranty:12 months
Packing:Antistatic bag /white box and standard export carton/customized
Packaging & Delivery :
. Netural labels,Polybag,PVC,Color box,Customised package
. Netrual packing/Cartoon box with less than 10KGS
. Delivery Detail:sample within 10 work days,25~35 days for bulk order
Product Advantages:
1). Green product
2). Long standby time
3). One year warranty
4). Excellent safety performance
5). Excellent storage performance and low self-discharge rate
6). Short circuit testing passed
7). Overcharge testing passed
8). Over discharge testing passed
9). 150ºC thermal shock test passed
10).1.2m drop testing passed
Spotlight:
1).Provide both single cells and battery packs
2).100% inspection before delivery
3).Inspects inner resistance,discharge platform and self-discharge
4). manufacturer of 26650 lifepo4 battery etc.
5).tablished quality control systems under ISO9001
6).Customized packs, tags,labels,plugs,connectors,over current protection,temperature contol protection are available
Shipping terms:
1).Samples checking: sending by Express ( DHL/UPS/FEDEX/TNT,by air)
2).Bulk production: sending out by cargo shipping / air freight / Express(DHL/UPS/FedEx/TNT),or we can accept other shipping terms according to your requirements.
3).We are not responsible for any accidents, delays or other issues that are caused by the shipping.
Safety Precaution:
1).Do not throw battery into water or make it wet;
2).Keep the battery away from heat source(like fire or heater);
3).Do not throw the battery into fire or heat the battery;
4).Forbid to hammer to trample the battery;
5).Forbid disassembling the battery in anyway
Call us to know more details datasheet.
Brand Name:QUAWIN/OEM
Model Number:LP128-960K-F(26650)
Type:Lifepo4 LFP battery
Place of Origin:Guangdong China (Mainland)
Nominal Capacity:96Ah/96000mAh
Cell Capacity:3.2V/3.0Ah
Nominal Voltage:12.8V
Charging voltage:DC:14.6V CC/CV
Optional function: intelligent battery display module
Maximal charging curren:150a
Maximal continuous Discharging current:150a
Discharge overcurrent protection:400±50A
Over charge detection voltage:15.2±0.025V
Over charge release voltage:14.2±0.025V
Over discharge detection voltage:8.0±0.05V
Over discharge release voltage:9.2±0.05V
Blanse current for single cell:56mA±5mA
BMS Models:PCM-L10S200-C49(BMS specifications can be obtained separately)
Certificate:CE,ROHS,UL,UN38.3 REACH
Pack:Fiberboard wrapping and PVC shrinkage film
Battery Pack Dimension :345(T) x 175(W) x 215(H)mm
Weight:14.3Kg
Composed Type:4S32P
Cycle life:2000~3000 times
Warranty:12 months
Packing:Antistatic bag /white box and standard export carton/customized
Packaging & Delivery :
. Netural labels,Polybag,PVC,Color box,Customised package
. Netrual packing/Cartoon box with less than 10KGS
. Delivery Detail:sample within 10 work days,25~35 days for bulk order
| Recommended Charger: | QW128-300-F |
| Charger input: | AC 100-240VAC 50/60Hz |
| Charging mode: | constant voltage constant current (CC/CV) |
| Charging voltage: | 14.6V |
| Charging current: | 30a(Max) |
| Charging time: | 3-4 hrs(standard) |
| Charger working instruction: | Waiting Mode:LED(GREEN) ON Charging Mode:LED(BLUE) FLASH Full Charged Mode:LED(GREEN) ON Charge Error Mode:LED(RED) FLASH |
Product Advantages:
1). Green product
2). Long standby time
3). One year warranty
4). Excellent safety performance
5). Excellent storage performance and low self-discharge rate
6). Short circuit testing passed
7). Overcharge testing passed
8). Over discharge testing passed
9). 150ºC thermal shock test passed
10).1.2m drop testing passed
Spotlight:
1).Provide both single cells and battery packs
2).100% inspection before delivery
3).Inspects inner resistance,discharge platform and self-discharge
4). manufacturer of 26650 lifepo4 battery etc.
5).tablished quality control systems under ISO9001
6).Customized packs, tags,labels,plugs,connectors,over current protection,temperature contol protection are available
Shipping terms:
1).Samples checking: sending by Express ( DHL/UPS/FEDEX/TNT,by air)
2).Bulk production: sending out by cargo shipping / air freight / Express(DHL/UPS/FedEx/TNT),or we can accept other shipping terms according to your requirements.
3).We are not responsible for any accidents, delays or other issues that are caused by the shipping.
Safety Precaution:
1).Do not throw battery into water or make it wet;
2).Keep the battery away from heat source(like fire or heater);
3).Do not throw the battery into fire or heat the battery;
4).Forbid to hammer to trample the battery;
5).Forbid disassembling the battery in anyway
Call us to know more details datasheet.
