Basic Info.
Model NO.
ELT5/10/15-5LEU
Rechargeable
Yes
Size
Large
Voltage
48V
Capacity
100ah 200ah 300ah 400ah 500ah 600ah 700ah 800ah
Energy
5kwh, 10kwh, 15kwh, 20kwh, 30kwh, 40kwh, 50kwh
Certification
CE/RoHS/Un38.3/MSDS
Self Discharge Rate
<3%
Weight
43 Kg
Warranty
5 Years
Cycle Life
6000 Times
Display Screen
Yes
Parallel Connection
Available
Features
Stackable
Application 1
Home Energy Storage, Residential Energy Storage
Application 2
Solar Energy Storage, Back up Power
Transport Package
Carton Box
Specification
595*400*181.5
Trademark
Elite/OEM
Origin
Guangdong, China,
HS Code
8507600090
Production Capacity
100000PCS/Month
Packaging & Delivery
Package Size
65.00cm * 25.00cm * 95.00cm
Package Gross Weight
70.000kg
Product Description
Elite New Energy Co., Ltd. is an Original Lithium Ion LiFePO4 Battery Pack Manufacturer with 15+ years Experience in Energy Storage System(ESS) and Motivation Power System Industry. Including High Voltage, 48V 100Ah Stackable Low Voltage Battery Packs,PowerWall Li ion Battery Pack,All in One Home Storage Solar System Battery,Lithium Power Battery for Solar and Golf Cart Diy Modify Coversion Kit.Our factory is Located in Dongguan, China, we also own two subsidiaries in United States of America, Czech Republic, Covering an Area of 10,000 Square meters, with annual production capability of 1GWH. Equipped with state-of-art facilities and equipment, certified with ISO9001, ISO14001 and ISO45001, complied with up-to-date certifications: CE RoHS, BIS, MSDS, UN38.3, Elite's products perfectly meet international standards with most excellent performance and safety compliance, and fully qualified for high and OEM/ODM markets.
ELITE 48V 100Ah 5KWh 10KWh 15KWh Stackable All In One Energy Storage Lithium Ion Battery
This multiple stacked battery/system is our most popular model for home energy storage application. You can either choose to create a battery system or an all-in-one energy storage system, which is very flexible and with nice look. Below are the product features:
1. Flexible connection and 4 different installation waysby option (Wall mounted, Rack mounted, Horizontally /Vertically Stackable).
2. Battery supports max. 30pcs in parallel connection to increase capacity, up to 150kwh.
3. Inverter supports max. 9pcs in parallel connection to get larger output power or three phase output.
4. Besides Elite inverter, the stacked battery system is widely compatible with main brand inverters.
5. Optional intergation of inverter to all-in-one energy storage system.
6. With Bluetooth and WIFI module to monitor battery or system on Phone App.
7. Excellent high temperature and safety performance.
1. Flexible connection and 4 different installation waysby option (Wall mounted, Rack mounted, Horizontally /Vertically Stackable).
2. Battery supports max. 30pcs in parallel connection to increase capacity, up to 150kwh.
3. Inverter supports max. 9pcs in parallel connection to get larger output power or three phase output.
4. Besides Elite inverter, the stacked battery system is widely compatible with main brand inverters.
5. Optional intergation of inverter to all-in-one energy storage system.
6. With Bluetooth and WIFI module to monitor battery or system on Phone App.
7. Excellent high temperature and safety performance.
Battery System Parameter
| Battery Module Parameters | ||||||
| Nominal Voltage | 51.2V | |||||
| Rated Capacity | 100Ah | |||||
| Battery Cell | LFP-3.2V 100Ah | |||||
| Rate Power | 5120Wh | |||||
| Charge Cut-off Voltage | 58.4V | |||||
| Discharge Cut-off Voltage | 40V | |||||
| Max. Charge Current | 100A | |||||
| Max. Discharge Current | 100A | |||||
| Peak Discharge Current | 150A | |||||
| Internal Impedance | ≤100mΩ | |||||
| Display | SOC LED Indicator | |||||
| Communication | CAN/RS485/RS232 | |||||
| Dimension(L*W*H±2mm) | 592*400*176mm | |||||
| Weight | 43Kg | |||||
| Operation Temperature Range | Charge:0~55ºC Discharge: -20~65ºC Storage: 0~55ºC | |||||
| Maximum Installation Height | Max. 4pcs for vertical stacked installation; Max. 6pcs for horizontal stacked installation | |||||
| Cycle Life | ≥ 6000 cycles | |||||
| Number of Parallel Connection | Max. 30pcs | |||||
| Color | Optional | |||||
| Battery System Parameters (Takes horizontal stacked installation type as an example) | ||||||
| Number of Battery Modules | 1 | 2 | 3 | 4 | 5 | 6 |
| Nominal Voltage | 51.2V | |||||
| Rated Capacity | 100Ah*1 | 100Ah*2 | 100Ah*3 | 100Ah*4 | 100Ah*5 | 100Ah*6 |
| Rated Power | 5.12kWh | 10.24kWh | 15.36kWh | 20.48kWh | 25.60kWh | 30.72kWh |
| Max. Charge/discharge Current | 100A | 200A | 300A | 400A | 500A | 600A |
| Peak Discharge Current | 150A | 300A | 450A | 600 | 750A | 900A |
| Dimension(L*W*H±2/mm) | 595*400*246 | 595*500*422 | 595*400*598 | 595*400*774 | 595*400*950 | 595*499*1126 |
| Weight | 48Kg | 91Kg | 134Kg | 177Kg | 220Kg | 263Kg |
All-in-one Energy Storage System Parameter
| Item | Parameters | ||
| Performance | |||
| Model | ELT5-5LEU | ELT10-5LEU | ELT15-5LEU |
| Number of Battery Modules | 1 | 2 | 3 |
| Number of Inverter Module1 | 1 | ||
| Nominal Energy | 5.12KWh | 10.24KWh | 15.56KWh |
| Dimension (L*W*H/mm) | 592*176*870 | 592*176*1270 | 592*176*1670 |
| Weight | 70kg | 113kg | 156kg |
| AC Output | |||
| Rated Output Power | 5KW | ||
| Max.Peak Power | 10KVA | ||
| Rated Output Voltage | 230Vac, single-phase | ||
| Rated AC Frequency | 50Hz/60Hz | ||
| PV Input | |||
| Number of MPPT Trackers | 1 | ||
| Max. Input Current | 18A | ||
| Max.Voltage of Open Circuit | 500Vdc | ||
| PV Voltage Range | 120-450Vdc | ||
| Optimum Vmp working range | 280-400Vdc | ||
| Grid Input | |||
| Input Voltage Range | 170~280Vac(UPS); 120~280Vac(Home Load) | ||
| Frequency Range | 50Hz/60Hz | ||
| Bypass overload current | 40A | ||
| Power efficiency | >95% | ||
FAQ Q1. Do you have MOQ (Minimum Order Quantity) Limit?
A: No, Elite do not have MOQ limit, 1 pieces sample order or small quantity is available.
Q2. What about the Lead time?
A: Standard product lead time: Samples: 3-5 days, Bulk order: 3-4 weeks.
Customized product lead time: 3-4 weeks both for sample or bulk order.
Q7: Do I have to buy a special charger for LiFePO4 batteries?
A: We recommend using a lithium iron phosphate 4-string (14.6V) charger to charge the battery.Additionally, you have two other options:
Scheme 2: You can use photovoltaic solar panels to charge the battery through MPPT.
Scheme 3: You can use an inverter with a built-in AC to DC charging function to charge the battery pack.
Q8: What is a BMS? A: A Battery Management System (BMS) is responsible for protecting the li-ion cells and the user from unsafe operating conditions, such as low or high voltage, low or high temperatures, and system shorts. It shuts off the battery to prevent damage.Our BMS also ensures cell balance. During each charge cycle, it reduces the charging rate in cells that have been topped off first, allowing other cells to catch up. This maintains cell balance and ensures the quality and efficiency of the battery pack.
Q9: How long do LiFePO4 batteries last?
Q10: Are your Batteries safe?
A: Our LiFePO4 batteries are manufactured using automotive-grade LiFePO4 cells, offering higher energy density, no memory effect, more stable performance, and greater power.The stable Lithium Iron Phosphate chemical structure makes LiFePO4 batteries resistant to burning or exploding, even at high temperatures, short circuits, impact, and drops. They have been tested and certified for safety by CE.Our batteries do not contain heavy metals or rare metals, making them more environmentally friendly. They are often referred to as green batteries.All our lithium battery products have a built-in battery management system (BMS) that protects against overcharge, deep discharge,overload, overheating, and short circuit. The BMS also ensures a low self-discharge rate.Furthermore, our BMS has a high-temperature disconnect function. When the internal battery temperature reaches 75°C (167°F), it automatically disconnects to protect the battery. It also disconnects if the overcharge voltage exceeds 15V or the overdischarge voltage drops below 8.8V.
Ask More
A: No, Elite do not have MOQ limit, 1 pieces sample order or small quantity is available.
Q2. What about the Lead time?
A: Standard product lead time: Samples: 3-5 days, Bulk order: 3-4 weeks.
Customized product lead time: 3-4 weeks both for sample or bulk order.
US & EU Warehouse Ready to Ship Products Can shipping out once your payment confirmed.
Q3. How do you ship the goods? How about the Shipping time?
A: By air door to door (6-12 days): FEDEX, UPS or DHL, suitable for urgent small order.
By sea door to door (25-50 days): suitable for bulk order.
By sea to delivery port (20-35 days): Suitable for bulk order.
By Air to airport (3-5 days): Suitable for urgent heavy package.
Q4. How to proceed with an order?
A: Firstly, providing your requirements or applications, then we will provide battery solution and quote accordingly.
Secondly, confirming the order and do the deposit for it, then we will arrange the production.
Q5. Is it available to print my logo on the product?
A: Yes. For OEM Demand Just send us your logo and we will make a label for the product. For product with metal/aluminum case, logo silk-print on the case is available.
Q3. How do you ship the goods? How about the Shipping time?
A: By air door to door (6-12 days): FEDEX, UPS or DHL, suitable for urgent small order.
By sea door to door (25-50 days): suitable for bulk order.
By sea to delivery port (20-35 days): Suitable for bulk order.
By Air to airport (3-5 days): Suitable for urgent heavy package.
Q4. How to proceed with an order?
A: Firstly, providing your requirements or applications, then we will provide battery solution and quote accordingly.
Secondly, confirming the order and do the deposit for it, then we will arrange the production.
Q5. Is it available to print my logo on the product?
A: Yes. For OEM Demand Just send us your logo and we will make a label for the product. For product with metal/aluminum case, logo silk-print on the case is available.
Q6: Does the BMS have low temperature charging disconnect? A: Yes, of course! If you purchase our battery with low-temperature cutoff,our BMS has low-temperature protection cut-off function to protect your battery from low-temperature damage and extend battery life.
Low temp cut off protection (Charge): 0ºC ± 4ºC (32°F ± 39.2°F)
Low temp cut off protection (Discharge): -20ºC ± 4ºC (-4°F ± 39.2°F)
Low temp cut off protection (Charge): 0ºC ± 4ºC (32°F ± 39.2°F)
Low temp cut off protection (Discharge): -20ºC ± 4ºC (-4°F ± 39.2°F)
Q7: Do I have to buy a special charger for LiFePO4 batteries?
A: We recommend using a lithium iron phosphate 4-string (14.6V) charger to charge the battery.Additionally, you have two other options:
Scheme 2: You can use photovoltaic solar panels to charge the battery through MPPT.
Scheme 3: You can use an inverter with a built-in AC to DC charging function to charge the battery pack.
Q8: What is a BMS? A: A Battery Management System (BMS) is responsible for protecting the li-ion cells and the user from unsafe operating conditions, such as low or high voltage, low or high temperatures, and system shorts. It shuts off the battery to prevent damage.Our BMS also ensures cell balance. During each charge cycle, it reduces the charging rate in cells that have been topped off first, allowing other cells to catch up. This maintains cell balance and ensures the quality and efficiency of the battery pack.
Q9: How long do LiFePO4 batteries last?
A: Our LiFePO4 lithium iron batteries provide 4000+ cycles, compared to 300-500 cycles in lead-acid batteries. The service life of LiFePO4 batteries is 8 to 10 times longer than standard lead-acid batteries.
Q10: Are your Batteries safe?
A: Our LiFePO4 batteries are manufactured using automotive-grade LiFePO4 cells, offering higher energy density, no memory effect, more stable performance, and greater power.The stable Lithium Iron Phosphate chemical structure makes LiFePO4 batteries resistant to burning or exploding, even at high temperatures, short circuits, impact, and drops. They have been tested and certified for safety by CE.Our batteries do not contain heavy metals or rare metals, making them more environmentally friendly. They are often referred to as green batteries.All our lithium battery products have a built-in battery management system (BMS) that protects against overcharge, deep discharge,overload, overheating, and short circuit. The BMS also ensures a low self-discharge rate.Furthermore, our BMS has a high-temperature disconnect function. When the internal battery temperature reaches 75°C (167°F), it automatically disconnects to protect the battery. It also disconnects if the overcharge voltage exceeds 15V or the overdischarge voltage drops below 8.8V.
Ask More
