Basic Info.
Model NO.
Ifr22650 Ifr22500 3.2V 2000mAh Cell
Nominal Voltage
3.7V
Discharge Rate
Low Discharge Rate
Shape
Cylindrical Battery
Electrolyte
Li-ion
Installation
Fixed
Rechargeable
Chargeable
Transport Package
Carton
Trademark
FOBERRIA
Origin
Made in China
HS Code
8506500000
Product Description
>Main Features
>Specification
>Applications
1.UPS backup power supply,
2.Solar energy,
3.Wind energy system
4.Solar street light,
5.Lawn lights and other lighting systems
1.Using lithium iron phosphate battery technology process, higher safety;
2.100% DOD charge and discharge under standard conditions, more than 3000 cycles;
3.Built-in automatic protection device to prevent over-charge, over-discharge,over-current and over-temperature;
4.Maintenance-free, can replace lead-acid batteries;
5.Light weight, about 40%~50% of the weight of lead-acid batteries.
2.100% DOD charge and discharge under standard conditions, more than 3000 cycles;
3.Built-in automatic protection device to prevent over-charge, over-discharge,over-current and over-temperature;
4.Maintenance-free, can replace lead-acid batteries;
5.Light weight, about 40%~50% of the weight of lead-acid batteries.
>Specification
| Model | ICR18650 3.7V 2200mAh | |||
| Nominal Voltage | 3.7V | |||
| Nominal capacity | 2200mAh | |||
| Charging method | Constant current 1C to 4.2V,then charge with constant voltage 4.2V till charge current less than 0.01C | |||
| Cycle life | 500 times(1C Charge / 1C discharge, capacity retention rate of ≥ 70%, 100%DOD) | |||
| Discharge ending voltage | ≤3.1V | |||
| Charging temperature | 0~55°C | |||
| Discharge temperature | -20~60°C | |||
| Max. charge voltage | 4.2V | |||
| Max charge current | 0.5C | |||
| Max Working current | 1.5C | |||
| Standard charge Current | 0.2C | |||
| Standard working current | 0.5C | |||
| Dustproof waterproof level | IP65 | |||
| Alternating Internal Resistance | ≤30 mΩ | |||
| Storage Temperature | less than 1 month | -20~+45°C | Recommended storage temperature: 20ºC,at the shipment state | |
| less than 3 months | -20~+35°C | |||
| Dimension | Height: 65mm Diameter:20 mm | |||
| Weight | Approx 55.8g | |||
>Applications
1.UPS backup power supply,
2.Solar energy,
3.Wind energy system
4.Solar street light,
5.Lawn lights and other lighting systems
